| Specification |
M6323A |
M6323B |
M6325 |
M6325A |
M6325B |
M6325C |
M6325D |
MU6325 |
M6330 |
M6330A |
M6333 |
| Working table(mm) |
230x1067,230x1246 |
254x1270, 254x1370 |
250x1270 |
305x1370,305x1500 |
330x1370
330x1500 |
| Longitudinal travel(mm) |
650,840 |
850,950 |
770 |
870,1000 |
840,1000 |
| Cross travel(mm) |
305 |
420 |
400 |
420 |
420 |
380 |
368 |
| Vertical travel |
400mm |
420mm |
400mm |
430mm |
450mm |
| Spindle hole taper |
R8, ISO30/ISO40(Optional) |
ISO40 |
R8 ,ISO30/ISO40 |
ISO40 |
| Spindle travel |
127mm |
| Auto-quill feed |
0.04,0.08,0.15mm |
| Spindle speed |
Variable
Speed |
65-4500rpm(Optional) |
65-3750rpm(Optional) |
65-4500rpm |
65-4200rpm
65-3750rpm |
| Step speed |
16steps 80-5440rpm |
16setps
80-5440rpm |
16steps 80-3750rpm |
16setps 80-5440rpm |
| Spindle motor |
2.25kw |
3.75kw |
2.25kw |
3.75kw |
3.75kw |
| Dimensions(cm) |
140x148x203 |
152x155x208 |
157x165x208 |
180x202x218 |
| Gross weight(kg) |
1110 |
1160 |
1550 |
1380 |
1420 |
1590 |
1590 |
1650 |
1700 |
1750 |
2300 |
| Model |
Feature application |
| M6323B |
Y axis swallowtail guidway; Z axis rectangular guidway |
| M6325A |
X, Z axis swallowtail guidway |
| M6325B |
Y axis rectangular guidway; Z axis swallowtail guidway |
| M6325 |
Y, Z axis rectangular guidway |
| M6325C |
Fixed structure is used to connect the mill head without ram; Y, Z axis rectangular guidway |
| M6325D |
Y, Z axis rectangular guidway |
| MU6325 |
Y, Z axis rectangular guidway; The machine can automatically feed with X and Y axis |
| M6330 |
Y, Z axis rectangular guidway |
| M6330A |
Fixed structure is used to connect the mill head without ram; Y, Z axis rectangular guidway |
| M6333 |
Fixed structure is used to connect the mill head without ram; Y, Z axis rectangular guidway | |
| |
|
| |
|
|
