| Specification |
D5050
D5050A |
D5040 D5040A |
D5035A |
D5032
D5032A |
D5030
D5030A |
D5025 |
| Max. drilling capacity(mm) |
50 |
40 |
35 |
32 |
30 |
25 |
| Max. thread-cutting |
M30/M27mm |
M27mm |
M24mm |
M20mm |
M20mm |
M16mm |
| Quill stroke(mm) |
180/240 |
180/240 |
200 |
160 |
135 |
130 |
| Spindle to column distance |
360mm |
360mm |
330mm |
350mm |
320mm |
240mm |
| Max. spindle to table distance |
600mm |
560mm |
630mm |
850mm |
620mm |
800mm |
| Quill stroke of spindle box |
|
|
|
320 |
|
140 |
| Max. spindle to foot distance |
1200mm |
1200mm |
1200mm |
1400mm |
1180mm |
1120mm |
| Max. adjustment of work table and table rest(mm) |
370/560 |
480 |
520 |
550 |
550 |
600 |
| Swivel of spindle box |
|
|
|
+ /-45o |
|
|
| Swivel of table |
+ 45o |
+ 45o |
+ 45o |
+ 45o |
+ 45o |
+ 45o |
| Spindle bore taper (morse) |
MT4 |
MT4 |
MT4 |
MT4 |
MT4 |
MT3 |
| Spindle speed steps |
|
12 |
12 |
12 |
12 |
12 |
| Spindle speed range (rpm) |
48-1500/42-2050 |
42-2050 |
70-2600 |
72-2600 |
72-2600 |
125-2880 |
| Spindle speed range |
4 |
4 |
3 |
3 |
3 |
|
| Feed range |
0.08-0.35 |
0.07-0.40 |
0.1/0.2/0.3 |
0.1/0.2/0.3 |
0.1/0.2/0.3 |
|
| Effective table dimensions |
510x380 |
510x380 |
450x390 |
500x450 |
500x450 |
Ф170 |
| Base plate dimensions (mm) |
450x440 |
450x440 |
405x395 |
370x360 |
405x395 |
315x320 |
| A.C. motor power(kw) |
3.3/4, 2.2/2.8 |
2.2/2.8kw |
1.5/2.2kw |
1/1.5kw |
1/1.5kw |
0.85/1.1kw |
| Net weight(kg) |
670 |
690 |
550 |
500 |
440 |
320 |
| Packing size(cm) |
110x67x215 |
110x67x215 |
100x61x215 |
103x61x209 |
94x57x225 |
88x57x190 |
FEATURE AND APPLICTION
Model |
Feature and application |
| D5050 |
Spindle stepless. Auto feed. The worktable can be rotated 360°and can be tilted + 45°,both motor-drive and manual-operated lifting device. Equipped withCoolant system, fender, shortcutand over load protection and tapping mechanism. Auto feed handle with special button. This button can be on or off at any; Time when boring and tapping. Easy operation. |
| D5040A |
Auto feed. The worktable can be tilted + 45°,both motor-drive and manual-operated lifting device. Equipped with coolant system, fender, shortcut and over load; Protection and tapping mechanism. Auto feed handle with special button. This button can be on or off at any time when boring and tapping. Easy operation. |
| D5035A |
Auto feed. The worktable can be tilted + 45°.Equipped with coolant system, fender, shortcut and over load protection and tapping mechanism. Auto feed Handle with special button. This button can be on or off at any time when boring and tapping. Easy operation |
| D5032A |
Spindle box can be rotated + 180°and can be inclined + 45°. It also can move up and down. The working table can be rotated 360°and can be tilted + 45° Equipped with fender, shortcut and over load protection and tapping mechanism. Auto feed handle with special button. This button can be on or off At any time when boring and tapping. Easy operation. The coolant system just as special accessories |
| D5032 |
Spindle box can be rotated + 180°and can be inclined + 45°and also can be move up and down. The worktable can be tilted + 45°. Equipped with fender |
| D5030A |
Auto feed. The worktable can be tilted + 45°. Equipped with coolant system, fender, shortcut and over load protection and tapping mechanism. Auto feed handle with special button. This button can be on or off at any time when boring and tapping. Easy operation |
| D5030 |
Worktable can be tilted + 45°. Equipped with fender. |
| D5025 |
Worktable can be tilted + 45°. Equipped with fender |
